Understanding CRGO | CRGO vs CRNO Explained

Materials matter in the transformers and power equipment business. CRGO or Cold-Rolled Grain-Oriented steel is one of the most essential materials used today. CRGO is used in static applications like transformer cores and static reactors where the magnetic flux flows in one direction. It is an important part of energy distribution networks as well as high-performance electrical machines due to its high efficiency, which results in less energy loss.

Image not Found

What is CRGO?

CRGO (Cold-Rolled Grain-Oriented steel) refers to a grade of electrical steel whose grain structure is highly oriented. This results in the steel conducting magnetic flux more easily in the rolling direction, due to the preferential orientation of the grain. This is the reason that CRGO is extensively used for transformer cores, where magnetic flux has to travel with low reluctance. Oh, and if you are still confused about what is CRGO, just imagine a high-performance silica-based steel that is accurately manufactured to conduct magnetic energy better than any standard steel.

Key Highlights:

  • Grain structure is oriented in the direction of magnetic flux
  • Transformer core loss reduction
  • High permeability and low coercivity
  • Crucial for energy-efficient electrical systems

CRGO Manufacturing Process

The process of CRGO manufacturing is very thorough, and it consists of multiple stages so that optimal grain orientation is achieved.

Steps Involved:

  • 1. Hot Rolling: The raw steel slab is hot rolled to a specific thickness.
  • 2. Cold Rolling: The steel is passed through rollers at room temperature to reduce thickness and refine the grain structure.
  • 3. Annealing: The cold-rolled steel is annealed to relieve internal stresses and start the grain orientation process.
  • 4. Coating and Insulation: A special insulation coating is applied to reduce eddy current losses.
  • 5. Final Annealing (High Temperature): A secondary high-temperature anneal completes the grain orientation process, enhancing magnetic performance.

Process Stage

Purpose

Hot Rolling

Initial thickness reduction

Cold Rolling

Refines grains, improves mechanical strength

Annealing

Aligns grain structure

Coating

Minimises eddy currents

Final Annealing

Perfects magnetic grain orientation

The result is a highly efficient, low-loss electrical steel suitable for core applications in transformers and reactors.

Properties of CRGO

The unique characteristics of CRGO make it the preferred choice for manufacturers looking to enhance energy efficiency in electrical machines.

Major Properties:

  • High Magnetic Permeability: Allows magnetic lines to pass with little resistance.
  • Low Core Loss: Reduces heat generation and energy loss in the transformer core.
  • Grain Orientation: Aligned grains make the material more magnetically efficient.
  • High Insulation Resistance: The coating minimizes eddy current losses

Property

Description

Magnetic Permeability

High (ideal for efficient flux conduction)

Core Loss

Very low compared to non-oriented steel

Thickness Range

The thickness range for CRGO steel is usually between 0.23 mm and 0.35 mm, though modern CRGO grades can go as thin as 0.18 mm

Electrical Resistivity

Enhanced with insulation coatings

Surface Insulation

Improves dielectric properties and reduces eddy losses

These properties of CRGO help reduce transformer noise, improve load handling, and ultimately lead to longer-lasting electrical infrastructure.

CRGO Grades

CRGO steel is available in several standard grades, each with varying levels of core loss and permeability. The most common grades are M3, M4, M5, and M6. The lower the number, the better the magnetic properties.

Overview of CRGO Grades:

Grade

Typical Thickness (mm)

Core Loss (W/kg at 1.5T)

Application Area

M3

0.23

~0.90

High-efficiency power transformers

M4

0.27

~1.00

Distribution transformers

M5

0.30

~1.15

General-purpose transformers

M6

0.35

~1.30

Low-cost applications where efficiency is secondary

  • M3 Grade: Highest performance, lowest loss—used in large power transformers.
  • M4 Grade: Balanced grade for cost and efficiency—common in medium transformers.
  • M5 and M6 Grades: Used in smaller units or where initial cost is a higher priority than minimal loss.

Choosing the right grade of CRGO depends on the specific application and performance expectations

CRGO Vs CRNO

When choosing electrical steel for transformers and other electromagnetic devices, two primary options come into play - CRGO and CRNO. While both are used in transformer core manufacturing, they differ significantly in structure, efficiency, and application suitability.

Let’s dive into a detailed CRGO vs CRNO comparison to better understand how these two materials differ and where each fits best.

Meaning & Definition

CRGO (Cold-Rolled Grain-Oriented steel) is a silicon steel specially processed so that the grains are oriented in one direction, optimizing magnetic properties along that axis.

CRNO (Cold-Rolled Non-Oriented steel) has randomly oriented grains, which makes it suitable for applications where magnetic flux flows in multiple directions.

Steel Type

Grain Orientation

Magnetic Efficiency

CRGO

Uni-directional

High

CRNO

Multi-directional

Moderate

Magnetic Properties Comparison

The magnetic performance of CRGO outshines CRNO, especially in applications requiring directional flux flow. CRGO has lower hysteresis and eddy current losses due to its aligned grain structure, resulting in higher efficiency.

  • CRGO: High permeability, low core loss, minimal energy waste
  • CRNO: Higher core losses due to irregular grain orientation

This makes CRGO the go-to material for energy-efficient transformers and power distribution systems.

Cost and Manufacturing Complexity

CRGO is more expensive and complex to manufacture than CRNO. The precise grain alignment in CRGO involves advanced rolling and heat treatment techniques, whereas CRNO can be produced with fewer processing steps.

Aspect

CRGO

CRNO

Manufacturing

Complex, precision-intensive

Simpler and quicker

Cost

Higher

More affordable

Availability

Limited to select suppliers

Widely available

Despite the higher cost, CRGO delivers better lifecycle value through energy savings.

Performance in Transformers

CRGO outperforms CRNO in large power and distribution transformers due to its lower core losses and better magnetic performance. CRNO is generally restricted to low-performance or budget applications like ballasts or small appliances.

  • CRGO: Used in high-voltage and energy-efficient transformers
  • CRNO: Suitable for low-voltage, small-scale uses

The difference in CRGO vs CRNO performance becomes evident when efficiency, temperature stability, and durability are crucial

Applications and Use Cases

CRGO finds its niche in high-performance sectors where energy efficiency and reliability are paramount. CRNO, on the other hand, is used in appliances and rotating machines where cost-saving is more important than top-tier efficiency.

Application Area

CRGO

CRNO

Power Transformers

High Efficiency

Not ideal

Ballasts & Motors

Rarely used

Common

Generators

Especially for static cores, as CRGO is suitable only for non-rotating parts (like static field poles or stationary core segments)

For rotating equipment

Household Appliances

Cost-prohibitive

Budget-friendly

Applications of CRGO

The unique magnetic and electrical properties of CRGO make it a fundamental material in modern energy infrastructure. Its efficiency in minimizing energy loss under alternating magnetic fields means it’s highly sought after in the following areas:

  • Power and Distribution Transformers: CRGO is the standard core material in both high-voltage and medium-voltage transformers due to its superior flux-handling capacity
  • Current Transformers (CTs) & Potential Transformers (PTs): High magnetic permeability makes CRGO ideal for accurate sensing equipment.
  • Reactors and Chokes: Used in power conditioning and filtering applications.
  • High-Efficiency Motors: Especially in stationary core parts to minimize losses.
  • Energy Grids: Widely used by utility providers for grid reliability and energy efficiency

Wherever energy conservation and electromagnetic precision are required, CRGO is there.

Mangal Electrical Industries Ltd.: Pioneers in CRGO Transformer Components

When it comes to reliable manufacturing and innovation in CRGO-based transformer components, Mangal Electrical Industries Ltd. stands as a trusted leader in the field. With decades of domain experience and adherence to the highest quality standards, Mangal has built a global reputation in the power infrastructure industry.

Why Mangal?

  • Expertise in CRGO: Mangal processes high-grade CRGO steel into precision-engineered components like slit coils, cut laminations, wound cores, and core assemblies.
  • Wide Range: From 5 KVA single-phase to 10 MVA three-phase transformer assemblies.
  • Certifications & Compliance: ISO 9001:2015, ISO 14001:2015, ISO 45001:2018, and approvals from NTPC, NABL, and PGCIL.
  • Testing Excellence: Equipped with Brockhaus Messtechnik systems aligned with ISO 3024:2015, IEC, and ASTM standards.
  • Innovation & Global Reach: Supplies CRGO-based components for various energy sectors across India and abroad.

With a mission to deliver energy-efficient, reliable, and cost-effective solutions, Mangal continues to drive excellence in CRGO transformer component manufacturing.

Conclusion

CRGO is a highly specialised steel known for its excellent magnetic properties, especially suited for high-efficiency transformers. Compared to CRNO, it offers superior performance but comes at a higher cost. Choosing between CRGO vs CRNO depends on factors like the required energy efficiency, budget, and end-use application. For critical power systems and precision-based equipment, CRGO remains the material of choice.

FAQs

1. What is CRGO, and why is it used for high-efficiency transformers?
CRGO continues to reduce core losses and increase magnetic permeability, resulting in reduced energy losses and improved transformer efficiency.
2. How does the grain orientation affect the properties of CRGO?
By orienting the grain, you align the magnetic domains, reduce the resistivity to magnetic flux, and thus reduce the energy wasted in the operation of a transformer core
3. What is the difference between CRGO and silicon steel?
CRGO stands for Cold-rolled Grain-oriented silicon steel because it has grains aligned in one direction, in comparison to regular silicon steel (like CRNO), which has randomly orientated grains and leads to a larger energy loss.
4. Can CRNO be used in large power transformers?
CRNO has a higher loss in the material core, so it is not normally suggested for large power transformers. It is more suitable for inexpensive, low-power, or rotating electrical applications.
